Geotextile Stabilization Fabric
It functions as a separation, filtration, drainage, and protection layer in civil and environmental engineering applications.
Description
Technical Parameters
Geotextile stabilization fabric is a permeable geosynthetic material designed to allow water flow while retaining soil particles.
It functions as a separation, filtration, drainage, and protection layer in civil and environmental engineering applications.
The fabric is commonly installed beneath or above geomembrane systems to provide protection against puncture from sharp aggregates and to maintain soil layer separation.
The material is manufactured from polyester or polypropylene fibers in either short-fiber (staple) or continuous filament forms.
Production processes include needle-punched nonwoven and woven construction, each providing different mechanical and hydraulic performance characteristics.
Functional Performance and Engineering Applications
The geotextile allows uniform water permeability, enabling efficient drainage and preventing water accumulation in soil structures.
At the same time, it retains fine soil particles, preventing soil migration and maintaining structural stability.
The material provides high tensile strength and excellent resistance to installation stresses without tearing or deformation.
It also offers chemical resistance to acids and alkalis commonly found in soil environments, ensuring long-term durability.
In addition, the fabric provides cushioning and protection when used in combination with geomembranes, reducing the risk of puncture from angular rock particles.
Typical mass per unit area ranges from 100 g/m² to 500 g/m², depending on project requirements.
Installation Efficiency and Manufacturing Capability
Geotextile stabilization fabric is lightweight and easy to install, enabling rapid coverage of large surface areas.
It maintains flexibility and performance under low-temperature conditions and does not become brittle in cold climates.
Available roll widths include 2 m, 4 m, and 6 m, with standard roll lengths of 50 m and 100 m.
Our factory has over 12 years of manufacturing experience in geosynthetic materials. We operate ISO9001-certified production systems with in-house laboratory testing and quality control.
We are a supplier to major infrastructure contractors including China Railway and China State Construction.
We provide OEM services, free samples, third-party inspection support, and a 1-year warranty. Each roll is fully inspected before shipment.
The minimum order quantity is 100 square meters per specification.
Technical Parameters
|
Parameter |
Value |
|
Product Code |
JRJH-TGB-022 |
|
Material |
Polyester / Polypropylene (staple or filament) |
|
Process |
Needle-punched / woven |
|
Mass per Unit Area |
100–500 g/m² |
|
Width |
2 m / 4 m / 6 m |
|
Roll Length |
50 m / 100 m |
|
Function |
Filtration / separation / drainage / protection |
|
Water Permeability |
High (uniform flow characteristics) |
|
Chemical Resistance |
Acid and alkali resistant |
|
MOQ |
100 m² per specification |
